Single Shaft Livestock Feed Mixer Short Mixing Cycle Low Energy Consumption

Single Shaft Livestock Feed Mixer Short Mixing Cycle Low Energy Consumption

Single Shaft Livestock Feed Mixer Short Mixing Cycle Low Energy Consumption

Product Details:

Place of Origin: China
Brand Name: AMEC
Certification: CE/ISO
Model Number: Cattle Feed Mixing Machine

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: standard exportation wooden case
Delivery Time: 7-9 work days
Payment Terms: T/T L/C Western Union
Supply Ability: 30 sets/month
Contact Now
Detailed Product Description
Item: Cattle Feed Mixing Machine Type: Horizontal Cattle Feed Mixing Machine
Voltage: 380/220V Or Customized Capacity: 500-3000kg/batch
Warranty: 12 Months Function: For Mixing Poultry Animal Cattle Feed

Single Shaft Livestock Feed Mixer Short Mixing Cycle Low Energy Consumption



This series Single-shaft cattle feed mixing machine is also called horizontal non-gravity mixer, it is an advanced mixing machine with high efficiency, high uniformity, high intensity, low energy consumption and low pollution. The machine is widely used for mixingpowder-powder and powder granule, especially suitable for materials with big difference in specific gravity or particle size.





Features of Single Shaft Cattle Feed Mixing Machine:

1. Short mixing cycle, high mixing homogeneity(CV≤5%);

2. Full length discharging door and quick discharging, low residue;

3. No deviation for long time mixing, many kinds of liquid addition are available;

4. Chain driving rigid design ensures operation without trouble for long time;

5. Compact structure, beautiful shape, low noise,no dust and environmental protection;

6. It is used for industries such as premix feed mill, compound feed mill,chemicals,etc.



Why do you choose our feed machine?

1. simple structure, wide adaptability, small floor area and low noise.

2. powder feed, grass powder does not need or a little liquid addition can be granulated, so the water content of grain feed is basically the moisture content of the material before granulation, which is more conducive to storage.

3. dry processing, the production of feed particles with high hardness, smooth surface, and internal aging, can improve animal digestion and absorption of nutrients.

4. the formation process of feed particles can make the pancreatic enzyme resistance factor in grain and legumes degeneration, reduce the adverse effects on digestion, kill all kinds of parasite eggs and other pathogenic microbes, and reduce the diseases of all kinds of insect pests and digestive system.



Main Parameters & Structure of  Single Shaft Cattle Feed Mixing Machine:

Model

Mixing Volume(m3)

Capacity(kg/batch)

Power(kw)

SJHS1A

1

500

11/15

SJHS2A

2

1000

18.5/22

SJHS4A

4

2000

37/45

SJHS6A

6

3000

55



1. Reducer: connection the main shaft and motor.

2. Siemens motor: we equip the super brand Siemens motor in our machine.

3. Main mixing chamber: the paddle is inisde. the paddle and the main mixing chamber could be made of complete stainless steel. just depend on your requirement if necessary.

4. Ventilating duct: keep the balance of air pressure in the mixing chamber.

5. Bearing: we adopt the super brand durable bearing in our machine.

6. Monitor window: we could monitor the running situation.



Single Shaft Livestock Feed Mixer Short Mixing Cycle Low Energy Consumption

We Focus on Complete Feed Production Line:

Single Shaft Livestock Feed Mixer Short Mixing Cycle Low Energy Consumption
