High Temperature Counterflow Cooler Low Residue Chicken Feed Pellet Cooler

High Temperature Counterflow Cooler Low Residue Chicken Feed Pellet Cooler

High Temperature Counterflow Cooler Low Residue Chicken Feed Pellet Cooler

Product Details:

Place of Origin: China
Brand Name: AMEC
Certification: CE/ISO
Model Number: Chicken Feed Cooler

Payment & Shipping Terms:

Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: standard exportation wooden case
Delivery Time: 7-9 work days
Payment Terms: T/T L/C Western Union
Supply Ability: 30 sets/month
Contact Now
Detailed Product Description
Item: Chicken Feed Cooler Function: Cooling Poultry Chicken Feed Pellet
Capacity: 3-20t/h Power: 1.12-2.05kw
Type: Counterflow Type Feed Pellet Cooling Application: Feed Pellet/wood Pellet Line

High Temperature Counterflow Cooler Low Residue Chicken Feed Pellet Cooler

Introduction of Counterflow Chicken Feed Cooler:

This series counterflow feed pellet woode pellet cooler adopts split type air feeder, which is closed to prevent the pellet mill with high temperature and high wet steam into the cooler then affect the cooling effect, and prevent the wind into.



Using adjustable ling conical dispersion device, the material can maximize evenly spread out in the bin. Advanced material level control, high degree of automation. May apply unmanned, special designed to slide valve type discharge mechanism, Uniform discharge, reliable work, cooling efficiency is very high.





Main Features & Applications of Counterflow Chicken Feed Cooler:

1. The counter flow chicken feed cooler cooling principle is adopted to cool the pellets with high temperature and moisture. Hot air touches hot pellets and cool air touches cool pellets so as to avoid the pellet surface crack caused by sudden cooling produced by direct touching between cool air and hot pellets. At the same time, the airlock is used for feeding and space of air inlet bigger, therefore it can get better cooling effects.
2. Slide reciprocating discharger has smooth and reliable discharging, low residue.
3. Low power consumption, easily operation.
4. Pellet temperature after cooling is less than +35 ambient temperature.
5. It is suitable for pellet cooling.





FAQ
1. Q: Are you a trading company or a manufacturer?
A:we are the manufacturer , which has about 37 years experience and own research and development team.
2. Q: How to order ?
A: Step 1, please tell us what model and quantity you need;
Step 2, then we will make a PI for you to confirm the order details;
Step 3, when we confirmed everything, can arrange the payment;
Step 4, finally we deliver the goods within the stipulated time.
3. Q: When will make delivery ?
A: Delivery Time
As usual, 7-15 days after getting payment. (Specific time according to order quantity)
4.Payment
L/C, T/T, Western Union, Paypal
5. Transportation
Transported by sea, by air or by express.
6. After-sales Service
As an experienced manufacturer, you can rest assured of the quality and after- sales service.



Main Parameters of Counterflow Chicken Feed Cooler:

Model SKLN14X14 SKLN17X17 SKLN20X20 SKLN24X24
Output(t/h) 3 5 10 20
Volume(m3) 1.5 2.5 4 8
Cooling time(min) >6-10 >6-10 >6-10 >6-10
Material temperature after cooling 3-5 degree higher than room temperature 3-5 degree higher than room temperature 3-5 degree higher than room temperature 3-5 degree higher than room temperature
Power(kw) 0.75+0.37 0.75+0.55 1.5+0.55 1.5+0.55



High Temperature Counterflow Cooler Low Residue Chicken Feed Pellet Cooler
